Transmitter

Rosemount 6081 Wireless Transmitter for pH and ORP and Conductivity

The 6081-P transmitter is ideal for monitoring applications,

especially in hard-to-reach or cost prohibitive locations.

6081-P measures pH and ORP and is compatible with most

Rosemount Analytical pH and ORP sensors.

The transmitter has a rugged, cast aluminum weatherproof and

corrosion resistant enclosure (NEMA 4X).

The transmitter includes a two-line 16-character display

with simple and intuitive menu screens.

Plain language prompts in six (6) local languages guide the

user through the programming and calibration procedures.

6081 is compatible with non-preamp pH and ORP sensors and

SMART pH sensors from Rosemount Analytical.

Installation and start-up of the 6081-P wireless transmitter

is simple.

Just power the 6081-P and assign it to a wireless network

with a 1420 Gateway.

The unit will auto-locate the most efficient path to the

host and will begin transmitting measurement data

immediately via 2.4 GHz wireless communications.

The Self-Organizing Network ensures exceptional data

reliability and network stability.

All of Emerson Process Management’s wireless devices employ

Encryption, Authentication, Verification, Anti-Jamming and

Key Management to ensure data transmission and security.

Rosemount Analytical devices include intelligent power

management to reduce power consumption and extend power

module life while delivering highly reliable measurements

with rich HART® data and diagnostic information.

HART digital communication allows access to AMS (Asset

Management Solutions) for live process variables, useful

diagnostics and troubleshooting information.

Device specification:
Products samples;
Proved: FM, CSA, ATEX;
Lifetime of power module: transmitter frequency 1m~3y;
Accuracy: ±1mV, 25°C ± 0.01 PH
Intrinsic safety, Two row character desplay;
Two points calibration;
Auto temperature compensation ;
Cast aluminium crust: NEMA 4X(IP65)
