Yokogawa UR10000 series paper recorder

    Yokogawa UR10000 series paper recorder

    • Place of Origin: Japan
    • Brand Name: Yokogawa
    • Model Number: UR10000
    • Product Name: Yokogawa UR10000 series paper recorder
    • Safety: good
    • Quality: International Standard for Yokogawa UR10000 series paper recorder
    • Accuracy: High Accuracy
    • Model: UR10000
    Mã: 1344-11660 Danh mục:
    • Yokogawa strip chart recorders µR10000 & µR20000
    1. Carryover of the µR1000/µR1800
    2. Bringing you the highest reliability
    3. Large VFD, Easy to Read
    4. Navigational Display
    5. Internal Illumination and New Chart Cassette
    6. Powerful Math Functions
    7. Variety of Networking Functions
    8. Application Software
    9. A Free Software Upgrade
    10. A Wealth of Recording and Printing Functions
    11. Adding New Functions
    12. (Calibration Correction, 24 VDC/AC Power Supply, Portable Type)
    • Retains the Same Powerful Specifications of the μR1000 and μR180
    µR10000 µR20000
    Measurement points Pen model: 1, 2, 3, or 4 pens Pen model: 1, 2, 3, or 4 pens
    Dot model: 6 dots (points) Dot model: 6, 12, 18, 24 dots (points)
    External dimension External 144 (W) x 144 (H) x 220 (D) mm 288 (W) x 288 (H) x 220 (D) mm
    dimensions (same as µR1000) (same as μR1800)
    Front door Splashproof and dustproof (IP-54)
    Terminal Same as µR1000 Same as µR1800
    positions
    Terminal 4 mm screw
    arrangement Input terminal: dot model (same), pen model (unified with the dot model)
    Option terminal: same
    Power supply terminal: same
    Weight (approx.) 2.1 kg (1 pen), 2.2 kg (2 pen), 7.5 kg (1 pen), 7.5 kg (2 pen),
    2.3 kg (3 pen), 2.4 kg (4 pen), 7.6 kg (3 pen), 7.6 kg (4 pen),
    2.5 kg (6 dot) 8.4 kg (6 dot), 8.6 kg (12 dot),
    8.8 kg (18 dot), 9.0 kg (24 dot)
    Power supply Rated supply voltage 100 to 240 VAC (auto switch)
    (same as µR1000/µR1800)
    Max. power consumption Pen: approx. 40 VA Pen, plotter pen, ribbon cassette, chart paper, shunt resistors, mounting brackets (same as µR1800)
    Dot: approx. 40 VA
    Fuse No need for maintenance
    General accessories Pen, plotter pen, ribbon cassette, chart paper, shunt resistors, mounting brackets (same as µR1000) Pen, plotter pen, ribbon cassette, chart paper, shunt resistors, mounting brackets (same as µR1800)
