SC72G Inductive Conductivity Converter Yokogawa portable conductivity meter
ISC450G Yokogawa portable conductivity meter is a 4-Wire type converter designed to measure specific conductivity by using the inductive conductivity method, which is especially suitable for high conductivity measurements. It features a unique accuracy and range ability, which is only possible through superior sensor design and electronic data processing using a self tuning amplifier with more than 10 sub ranges with automatic zero adjustment at every range change.
With tht EXAxt 450 unique Human Machine Interface (HMI), it not only present reliable process data, but also diagnostics, trends, logbooks and step by step calibration routines The high resolution graphical display and the touchscreen operation make all information visible to the operator.
SC72G Yokogawa portable conductivity meter owns below typical features:
1. Unique intuitive HMI menu structure in 8 languages
2. Process data trending up to 2 weeks
3. Predefined OIML standard solutions
4. Predefined matrices for precise temperature compensation
5. Two mA-outputs and four SPDT relay contacts with display indicators
6. % weight on display showed.
7. HART® Communications
8. Approval of FM Class I, Div. 2, Group ABCD, T6 for Ta -20 to 55ºC
|
SC72G SPECIFICATION
|
|
|
Input specification
|
Compatible with ISC40 inductive conductivity sensor with integrated temperature sensor: NTC30k or Pt1000
|
|
Detection method
|
inductive conductivity method
|
|
Input ranges
|
Conductivity: 0 to 1999 mS/cm at 25℃ (77℉)
Minimum: 1 μS/cm (at process temperature) Maximum: 2 S/cm (at process temperature) Temperature: -20 to 140℃ (0 to 280℉). |
|
Cable length
|
Max. 60 meters (200 feet). 10 meters (35 feet) fixed sensor cable + 50 meters (165 feet) WF10 extension cable.
|
|
Transmission Signals
|
Two isolated outputs of 4 to 20 mA DC with common negative. Maximum load 600 Ω. Bi-directional HART® digital communication, superimposed on mA1 (4 to 20 mA) signal. Burn up (21.0 mA) or burn down (3.6 mA) to signal failure accorded to NAMUR NE43.
|
|
Contact output
|
Four SPDT relay contacts with display indicators.
|
|
Contact input
|
Remote range switching to 10 times the programmed range
|
|
Temperature compensation
|
Automatic or manual, for temperature ranges. Reference temp. programmable from 0 to 100℃ or 30 to 210℉ (default 25℃).
|
|
Calibration
|
Semi-automatic calibration using pre-configured OIML (KCl) stanard tables, with automatic stability check. Manual adjustment to grab sample
|
|
Display
|
Graphical Quarter VGA (320 x 240 pixels) LCD with LED backlight and touch screen
|
|
Housing
|
Cast Aluminum housing with chemically resistant coating; Polycarbonate cover with Polycarbonate flexible window, Protection IP66/NEMA 4X/CSA Type 3S
|
|
Environment
|
Ambient Temperature: -20 to 55℃
Humidity: 10 to 90 % RH at 40℃ (non-condensing) |
|
Power supply
|
ISC450G-A:
Ratings; 100 to 240 V AC Acceptable range; 90 to 264 V AC Ratings; 50/60 Hz Acceptable range; 50 Hz ±5%, 60 Hz ±5% Power Consumption; 15 VA ISC450G-D: |
