Yokogawa EY200 Digital Earth Tester

Yokogawa EY200 Digital Earth Tester

  • Place of Origin: Japan
  • Brand Name: Yokogawa
  • Model Number: EY200
  • Product Name: Yokogawa EY200 Digital Earth Tester
  • Safety: good
  • Quality: International Standard for Yokogawa EY200 Digital Earth Tester
  • Accuracy: High Accuracy
  • Model: EY200
Mã: 1344-11330 Danh mục:
 The Yokogawa EY200 Digital Earth Tester is an earth resistance tester for testing power distribution lines, in-house wiring system, electrical appliances etc. The Yokogawa EY-200 also has an earth voltage range for earth voltage measurement.
A simplified 2-pole measuring method can be used if there is an almost perfectly earth/ground object such as a lead or iron water-pipe (plastic pipes cannot be used) or if there is an object with a known value of earth resistance, near the measurement site. The Yokogawa ey200 Digital Earth Tester is dust and drip resistant (IP54 rated).

Name

Model

Digital Earth Tester

EY200

EY200 General Specifications

Display

LCD Digital Display: 1999-count digital reading

Measuring Range

Earth Resistance: 2000Ω LSD: 0.01 to 1Ω Earth Voltage: 200V

Accuracy

Earth Resistance: 20Ω range: ±2%rdg±0.1Ω                              200Ω range: ±2%rdg±3dgt                              2000Ω range: ±2%rdg3dgt Earth Voltage:      ±1%rdg±4dgt

Measuring Frequency

Approx. 820Hz

Measuring Current

Approx. 3mA (at 20Ω range)

Battery Life

Approx. 4.5hours (at 5 second measuring 3300 times)

Operating Temp. and Humidity

0~40°C, 85%Rh or less

Dimensions

Approx. 105x158x70mm

Weight

Approx. 550g

Standard Accessories

3-pole Test Lead (Model 98074) Earth Spikes (for EY200) (Model 98070) 2-pole Test Lead Set (Model 98075) Soft Case (Model 93041) Shoulder Belt (for EY200) (Model 99018) Six AA (R6) dry cells User’s Manual
